Máy xúc lật bánh lốp mới QINGDAO PROMISING CE Front Loader ZL30F

3 ton capacity compact wheel loader with heavy-duty bucket with bolt on teeth, enclosed cabin with adjustable suspension seat and digital radio & MP3 player, hydraulic joystick, top beacon and air conditioner

Compact Wheel Loader ZL30F with CE

Technical Specifications

1. Rated Load: 3000kg

2. Operating Weight: 9600kg

3. Rated Bucket Capacity: 1.7CBM

4. Max. Tractive Force: ≥ 97KN

5. Max. Breakout Force: ≥127KN

6. Max Gradeability: 30Degree

7. Max. Dumping Height: 3100mm

8. Max. Dumping Reach: 1200mm

9. Raising Time: ≤6.0s

10. Total Cycle Time: ≤11s

11. Overall Dimensions (L x W x H): 7050x2430x3120mm

12. Min. Turning Radius: 5700mm

13. Engine Model: WEICHAI DEUTZ WP6G125E224

14. Engine Type: Vertical, Inline, Water-cooled Evaporative, Four-stroke Diesel Engine

15. Rated Engine Power: 92kW

16. Rated Engine Speed: 2200rpm

17. Max Torque: 500 N•m

18. Min. Fuel Consumption Rate: ≤210g/kW.h

19. Transmission Mode: YJ315-X Hydraulic Torque Converter

20. Gearbox Mode: Countershaft Constant-Mesh Power Shift

21. Gear Shift: 4 Forward Shift, 2 Reverse Shift

22. Max. Speed: 40km/h

23. Main Reducing Mode of Drive Axle: Bevel Gear Grade 1 Reduction

24. Hub Reduction Mode of Drive Axle: Planetary Reduction Grade 1

25. Wheel Tread: 1800mm

26. Wheel Base: 2660mm

27. Drive Mode: 4-wheel Drive

28. Hydraulic System Working Pressure: 16.5Mpa

29. Fuel Tank Capacity: 156L

30. Service Brake: Foot Pedal Vacuum Booster, Air over Hydraulic Caliper Discc Brake on 4 Wheels

31. Parking Brake: Hand Lever Flexible Shaft Controlled Disc Brake

32. Tyre Type Specification: 17.5-25-20PR

33. Front Tyre Pressure: 0.40Mpa

34. Rear Tyre Pressure: 0.35Mpa

Optional Parts and Functions:

Canopy, Open Cabin, FOPS/ROPS, Reversing Camera, Hydraulic Quick Hitch, Extra Hydraulic Lines, LED Lights, and Floating Function, etc.

Note:

1. The technical specifications are for standard models only.

2. Other optional accessories and requirements are available upon request.

3. All photos are for reference only. Machines shown may include optional parts.

4. All specifications and design characteristics are subject to change without prior notice.

5. For all available loader attachments, please refer to our Loader Attachments Catalogue.

6. Equipped with hydraulic quick coupler, your wheel loader can be easily and conveniently switched from one attachment to another to save your time and labor. Equipped with skid steer (Bobcat) quick coupler or Euro Standard quick coupler, you can use all your existing attachments with our wheel loader.
